Description
| Product characteristics | |
|---|---|
| Measuring range of vibration [mm/s] | 0...25; (RMS) |
| Frequency range [Hz] | 10...1000 |
| Application | |
| Application | vibration transmitter to ISO 10816 |
| Electrical data | |
| Operating voltage [V] | 9.6...32 DC |
| Protection class | III |
| Sensor type | microelectromechanical system (MEMS) |
| Inputs / outputs | |
| Total number of inputs and outputs | 1 |
| Outputs | |
| Analogue current output [mA] | 4...20 |
| Max. load [Ω] | < (Ub - 9,6 V) x 50; Ub = 24 V: 720 |
| Measuring/setting range | |
| Measuring range of vibration [mm/s] | 0...25; (RMS) |
| Frequency range [Hz] | 10...1000 |
| Number of measurement axes | 1 |
| Accuracy / deviations | |
| Measuring error [% of the final value] | < ± 3 |
| Repeatability | < 0,5; (% of the final value) |
| Linearity deviation | 0,25 % |
| Operating conditions | |
| Ambient temperature [°C] | -30...125 |
| Note on ambient temperature | |
| Storage temperature [°C] | -30...125 |
| Protection | IP 67; IP 68; IP 69K |
| Tests / approvals | |
| EMC | |
| Shock resistance | |
| Vibration resistance | |
| MTTF [years] | 868 |
| Mechanical data | |
| Weight [g] | 123.5 |
| Type of mounting | set screw |
| Materials | stainless steel (1.4404 / 316L) |
| Tightening torque [Nm] | 8 |
| Accessories | |
| Items supplied | |
| Remarks | |
| Pack quantity | 1 pcs. |
| Electrical connection | |
| Connection | Connector: 1 x M12; coding: A |
