Description
Part Number: EJA110E-JLH4G-712DD/D4
Model and Suffix Codes
Model: EJA110E - Differential pressure transmitter
Output signal: -J - 4 to 20 mA DC with digital communication (HART 5/HART 7 protocol)?
Measurement span (capsule): L -
Wetted parts material?: H
Cover flange and process connector: ASTM CF-8M?
Capsule: Hastelloy C-2764
Capsule gasket: PTFE Teflon
Vent/Drain plug: 316 SST
Process connections: 4 - with 1/2 NPT female process connector
Bolts and nuts material: G - 316L SST
Installation: -7 - Vertical piping, left side high pressure, and process connection downside
Amplifier housing: 1 - Cast aluminum alloy
Electrical connection: 2 - 1/2 NPT female, two electrical connections without blind plugs plug5
Integral indicator: D - Digital indicator5
Mounting bracket: D - 304 SST 2-inch pipe mounting, flat type (for horizontal piping)
Optional Codes: /D4 - Calibration Unit6 - M calibration (kgf/cm? unit)
