Description
Product Number: EJX110A-JMS5G-B19EN/KU22/M01
Model and Suffix Codes
Model: EJX110A - Gauge Pressure Transmitter
Output signal: -J - 4 to 20 mA DC with digital communication (HART 5/HART 7 protocol)
Measurement span (capsule): M - 0.5 to 100 kPa (2 to 400 inH2O)
Wetted parts material?: S -
Cover flange and process connector: ASTM CF-8M?
Capsule: Hastelloy C-276? (Diaphragm); F316L SST, 316L SST (Others)
Capsule gasket: Teflon-coated 316L SST
Vent/Drain plug: 316 SST
Process connections: *5 - without process connector (1/4 NPT female on the cover flanges)
Bolts and nuts material: G - 316L SST
Installation: -B - Bottom Process Connection, left side high pressure4
Amplifier housing: 1 - Cast aluminum alloy
Electrical connection: 9 - M20 female, two electrical connections and a blind plug5
Integral indicator: E - Digital indicator with the range setting switch (push button)6
Mounting bracket: N - None
Optional Codes:
/KU22: ATEX
Combined KF22, KS21 and ATEX Intrinsically safe Ex ic7,8
[ATEX Intrinsically safe Ex ic]
Applicable Standard: EN 60079-0:2012, EN 60079-11:2012
II 3G Ex ic IIC T4 Gc, Amb. Temp.: 30 to 60?C ( 22 to 140?F)9
Ui=30 V, Ci=27.6 nF, Li=0 H
/M01: Material certificate10 - Cover flange11
